Carling Technologies Tippette Full-Size Sealed Rocker Switch | SPST ON-None-Off | 20A 120-277VAC | Marine Bracket | Black with White Legend
4.5 (124 items)
Limited Time SaleUS$54.00 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 211068541 | Release Date | 2026/04/04 | List Price | US$36.00 | Model Number | 211068541 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Carling Technologies TIG-Series Tippette snap-in mounted rocker switches are traditionally styled full-sized switches appropriate for use in many general purpose applications. Contact Rating: 20A 120-277VAC. Marine Bracket option for an even higher level of splash protection. This bracketing option provides all the same protections as the water-shedding bracket, with additional safeguards including dummy rivets at all open terminal holes, a base seal between the switch bezel and base, and syntech grease to retard internal corrosion. Marine Bracketed switches provide the highest level of dust and water protection without having IP certification.
- Carling Technologies TIG-Series Tippette Rocker Switch TIGA721-6S-BL-MBL
- 2-Position On/Off SPST, Non-illuminated, O-I Legend
- Marine Bracket option for an even higher level of splash protection
- Two .250" wide Quick Connect tab terminals
- Fits mounting hole of 1.45" x .83" (36.83mm x 21.08mm)
| UPC | 760851710649 |
|---|---|
| Color | Black |
| Wattage | 5540 watts |
| Terminal | Quick Connect Tab |
| Brand Name | Carling Technologies |
| Unit Count | 1.0 Count |
| Switch Type | Rocker |
| Circuit Type | 1-way |
| Contact Type | Spst |
| Manufacturer | Carling Technologies |
| Actuator Type | Rocker |
| Material Type | Nylon, Phenolic |
| Mounting Type | Panel Mount |
| Connector Type | Quick Connect Tab |
| Control Method | Touch |
| Current Rating | 20 Amps |
| Operation Mode | ON-NONE-OFF |
| Item Dimensions | 1.75 x 1 x 2 inches |
| Number of Items | 1 |
| Contact Material | Brass |
| Operating Voltage | 120 Volts (AC) |
| Specification Met | CSA, UL |
| Number of Positions | 2 |
| Connectivity Protocol | X-10 |
| Upper Temperature Rating | 85 Degrees Celsius |
